Features
Parallel controls for light mixing boards via power line and DMX-signal via cable
Very good paired shielding of the DMX-cables due to tin plated copper braided shielding
Applications
Controls for DMX-light mixing board (surge impedance of 110 Ohm)
Analog + digital audio multipair with power supply
Cable Colour
Black

Technical Data
Order Code	PDC015
Total jacket, diameter	PVC 15.0 mm
No. of power conductors	3 x 1.5 mm²
Diameter of power cable	8.0 mm
No. of inner conductors	2 x 0.22 mm²
AWG	24
Copper strand per conductor	7 x 0.20 mm
Conductor insulation	PE 1.70 mm
Shielding	PE filler, tin plated copper braided shielding with 96 x 0.10 mm + AL
Shielding factor	100 %
Diameter of DMX cable	5.0 mm
Temperature range	min. -20 °C
Temperature range	max. +70 °C
Packaging	100/300 m roll

Electrical Data
Capac. cond./cond. per 1 m	47 pF(Signal)
Capac. cond./shield. per 1 m	102 pF(Signal)
Cond. resistance per 1 m	80 mΩ(Signal)
Shield. resistance per 1 m	18.2 mΩ(Signal)
